Flat Suction Multistage Pressure Pump
The MEDAS Flat Suction Multistage Pressure Pump (EC-RAIN Series) offers three or four stage design with 1mm low suction, allowing near-total drainage from rain barrels and tanks. Available with internal or external thread outlet options. Available 550W-1200W. OEM/ODM customization for global distributors.
Send Inquiry
Product Introduction
Products Description
Three stages/ four stages/ 1mm low suction
Technical specifcatio
| products |
 |
 |
 |
 |
|
MODEL |
EC_RAIN 550 INOX |
EC_RAIN 900 INOX |
EC_RAIN 1000 INOX |
EC_RAIN 1200 INOX |
|
Power |
550W |
900W |
1000W |
1200W |
|
Flow(L/H) |
6300 |
7000 |
7100 |
7300 |
|
Head(m) |
20 |
30 |
33 |
43 |
|
Outlet |
G1 |
G1 |
G1 |
G1 |
|
Solid |
1mm |
1mm |
1mm |
1mm |
|
Weight(kg) |
6.9 |
7.4 |
7.6 |
9 |
|
Loading q'ty(pcs) |
2300 |
2300 |
2300 |
2300 |
